Testing & Commissioning
Across All Systems

//OUR SERVICES

We provide a complete, integrated Testing & Commissioning service spanning electrical, mechanical, and monitoring systems, backed by our own CE-certified load bank equipment fleet.

Our scope covers the core mission-critical commissioning framework from CxL2 through CxL5 — moving seamlessly from component delivery, installation inspection, and pre-startup checks to dynamic functional performance testing (FPT) and full integrated systems testing (IST). Whether you're a data center operator, M&E consultant, or main contractor, we have the technical depth and the specialized equipment fleet to deliver.

ELECTRICAL SYSTEMS
Generator, UPS, Switchgear, PDU, Cable & Busway Systems
MECHANICAL SYSTEMS
Chillers, Pumps, Piping, Fanwall, CRAC, Liquid Cooling
MONITORING SYSTEMS
BMS, PMS, Fire Protection, Security, BAS, Network Cabling

// COMMISSIONING FRAMEWORK

CxL2 to CxL5 — Core Site Lifecycle

We support the data center commissioning framework for mission-critical environments. Engage our team for targeted level execution or for a complete, seamless CxL2–CxL5 site lifecycle.

CX Level 2
DELIVERY & PRE-STARTUP
Rigorous on-site inspection upon equipment arrival. We complete standardized delivery, storage, and architectural room readiness checklists. Every component is verified against approved submittals and inspected for physical installation quality before static dead testing begins.
CX Level 3
SYSTEMS START-UP
The critical path of safe equipment energization. Working closely with vendors and contractors, we execute pre-functional start-up scripts to validate exact firmware versions, operational setpoints, and localized control configurations. Systems are left fully operational and ready for dynamic testing.
CX Level 4
FUNCTIONAL PERFORMANCE TESTING
Dynamic, single-system validation. We push equipment to its operational limits, validating standalone control logic, specific sequences of operation, and critical safety interlocks against the design intent and OPR. Includes infrared thermographic scanning under load.
CX Level 5
INTEGRATED SYSTEMS TESTING
Holistic facility validation and failure mode simulation. We bring all mechanical, electrical, and monitoring systems together under artificial heat and power loads. Our team directs complex cross-system scenarios, including full black-building utility failures and redundant failovers, to prove total facility resilience.

// SERVICE SCOPE

What We Test & Commission

Deep-dive into our technical scope, structured for M&E consultants and procurement officers verifying tender requirements.

Generator Systems
Load bank testing, black-start validation, automatic transfer switch (ATS) testing, and governor response under simulated failure conditions.
UPS (Uninterruptible Power Supply)
Battery capacity verification, inverter bypass testing, redundancy validation, and runtime assessment under specified load profiles.
Switchgear & LV Panels
Low Voltage Power Module (LVPM) testing, switchgear functional checks, circuit protection verification, and interlock sequencing validation.
Power Distribution Unit (PDU)
Load balancing verification, branch circuit testing, remote monitoring integration checks, and redundancy path confirmation.
Power Cable System
HV/LV cable termination testing, insulation resistance measurements, high-potential testing, and continuity verification across entire cable runs.
Power Busway System
Busbar trunking system (BTS) commissioning, tap-off box verification, thermal imaging under load, and torque compliance checks.
Water-Cooled Chiller
Full load performance testing, COP verification, refrigerant circuit checks, condenser and evaporator validation, and capacity step testing.
Water Pump System
Flow rate balancing, differential pressure verification, VFD commissioning, and hydronic system flushing and cleanliness validation.
Piping System
Pressure testing, leak detection, flushing, chemical dosing verification, and isolation valve function tests across primary and secondary loops.
Fanwall & CRAC Units
Computer Room Air Conditioner (CRAC) and Fanwall commissioning — airflow balancing, temperature setpoint verification, and redundancy testing.
Liquid Cooling Systems
Next-generation direct-to-chip and rear-door heat exchanger commissioning. CDU validation, leak testing, and thermal performance verification.
Hybrid Liquid Cooling Banks
Specialised testing for liquid-cooled load banks mirroring thermal profiles of modern high-density data hall environments including immersion and chip cooling architectures.
Building Management System (BMS)
Full BMS commissioning — point-to-point verification, control sequence validation, alarm management testing, and integration with mechanical and electrical systems.
Power Monitoring System (PMS)
Energy meter calibration, CT ratio verification, PUE (Power Usage Effectiveness) baseline establishment, and real-time dashboard validation.
Fire Protection System
Detector sensitivity testing, suppression system discharge simulation, alarm panel integration, and interface with BMS and access control.
Security System
CCTV coverage validation, access control commissioning, intrusion detection testing, and integration with central monitoring platforms.
Building Automation System (BAS)
Sequence of operations verification, sensor calibration, control loop tuning, and full scenario simulation for HVAC and critical systems automation.
Network Cable System
Structured cabling verification, fibre and copper performance testing, patch panel certification, and end-to-end network continuity validation.

// SERVICE LIFECYCLE MANAGEMENT

Our 8-Step Service Lifecycle Management

A Comprehensive Framework for Operational Excellence

Beyond initial commissioning, we provide a structured lifecycle management program designed to maximize the lifespan and reliability of your critical infrastructure. Our rigorous 8-step process ensures that every component operates at peak performance with zero compromise on safety.

01

Preliminary Evalulation

Assess the hardware for deterioration or operational anomalies while recording current status logs.

02

Cleaning

Utilise cleaning instruments and approved agents to clear away debris.

03

Routine Servicing / Preventive Maintenance

Mechanical upkeep (i.e greasing moving elements, securing loose electrical interfaces.

04

Operational Testing

Execute system diagnostics to ensure that the unit consistently achieves specified targets.

05

Safety Assurance

Review and restore critical safety measures.

06

Documentation

Document all technical tasks, logs and maintenance for future auditing.

07

Final quality inspection

Validate total system integrity.

08

Client Feedback

Gather client insights and feedback to improve ongoing technical and commercial workflows.
